Quantity: | |
---|---|
Self-Starting Diesel Generator
Fixed
Four Stroke
Water Cooling
AC Three Phase
Speed
BS-FW125
Land Use
Common Units, Standby Unit, Emergency Crew
Ordinary
AC Rotating Exciter
Fawde Xichai Ca6df2-17D
Stamford
Smartgen,Deepsea...
Electric Start
100kw/125kVA
Optional
as Per Request
50Hz
400V
Packed in Plywood Cases or Wooden Cases or Foam, E
As for power
BOSSPOWER
China
85021200
100 Sets / Month
US$ 9000/Piece 1 Piece(Min.Order) | Request Sample
PRODUCT DESCRIPTION |
Frequency: 50HZ;Rotating speed: 1500Rpm | ||||||
Model | Power(KW) | Capacity(KVA) | Rated current(A) | Engine Model | Stamford Type | |
BS-FW16 | 12.8 | 16 | 23.1 | 4DW81-23D | BS164D | |
BS-FW23 | 18 | 22.5 | 32.5 | 4DW91-29D | BS184E | |
BS-FW28 | 22 | 27.5 | 39.7 | 4DW92-35D | BS184F | |
BS-FW30 | 24 | 30 | 43.3 | 4DW92-39D | BS184G | |
BS-FW35 | 28 | 35 | 50.5 | 4DX21-45D | BS184H | |
BS-FW40 | 32 | 40 | 57.7 | 4DX21-53D | BS184H | |
BS-FW50 | 40 | 50 | 72.2 | 4DX22-65D | BS224D | |
BS-FW63 | 50 | 62.5 | 90.2 | 4DX23-78D | BS224E | |
BS-FW73 | 58 | 72.5 | 104.6 | 4110/125Z-09D | BS224F | |
BS-FW94 | 75 | 94 | 135.3 | CA4DF2-12D | BS224G | |
BS-FW100 | 80 | 100 | 144.3 | CA6DF2D-14D | BS274C | |
BS-FW125 | 100 | 125 | 180.4 | CA6DF2-17D | BS274D | |
BS-FW150 | 120 | 150 | 216.5 | CA6DF2-19D | BS274F | |
BS-FW181 | 160 | 181 | 288.7 | CA6DL1-24D | BS274H | |
BS-FW225 | 180 | 225 | 324.8 | CA6DL2-27D | BS274J | |
BS-FW250 | 200 | 250 | 360.9 | CA6DL2-30D | BS274K | |
BS-FW300 | 240 | 300 | 433.0 | CA6DM2J-39D | BS314D | |
BS-FW300 | 240 | 300 | 433.0 | CA6DM2-39D | BS314D | |
BS-FW325 | 260 | 325 | 469.1 | CA6DM2J-41D | BS314E | |
BS-FW325 | 260 | 325 | 469.1 | CA6DM2-41D | BS314E | |
BS-FW375 | 300 | 375 | 541.3 | CA6DN1J-45D | BS314FS | |
BS-FW375 | 300 | 375 | 541.3 | CA6DN1-45D | BS314FS | |
Frequency: 60HZ;Rotating speed: 1800Rpm | ||||||
Model | Power(KW) | Capacity(KVA) | Rated current(A) | Engine Model | Stamford Type | |
BS-FW19 | 15 | 19 | 27.1 | 4DW81-28D | BS164D | |
BS-FW28 | 22 | 27.5 | 39.7 | 4DW91-38D | BS184E | |
BS-FW31 | 25 | 31 | 45.1 | 4DW92-42D | BS184F | |
BS-FW38 | 30 | 37.5 | 54.1 | 4DW92-45D | BS184G | |
BS-FW40 | 32 | 40 | 57.7 | 4DX21-53D | BS184G | |
BS-FW45 | 36 | 45 | 65.0 | 4DX21-61D | BS184H | |
BS-FW60 | 48 | 60 | 86.6 | 4DX23-82D | BS224D | |
BS-FW66 | 53 | 66.3 | 95.6 | 4DX23-90D | BS224E | |
BS-FW81 | 65 | 81 | 117.3 | 4110/125Z-11D | BS224F | |
BS-FW106 | 85 | 106 | 153.4 | CA4DF2-14D | BS274C | |
BS-FW119 | 95 | 119 | 171.4 | CA6DF2D-16D | BS274C | |
BS-FW138 | 110 | 138 | 198.5 | CA6DF2-18D | BS274D | |
BS-FW163 | 130 | 163 | 234.6 | CA6DF2-21D | BS274E | |
BS-FW206 | 165 | 206 | 297.7 | CA6DL1-27D | BS274G | |
BS-FW250 | 200 | 250 | 360.9 | CA6DL2-32D | BS274J | |
BS-FW338 | 270 | 338 | 487.2 | CA6DM2-42D | BS314D | |
BS-FW375 | 300 | 375 | 541.3 | CA6DN1-46D | BS314ES |
GENSET MODEL | BS-W125 | |
Rated Output (KW/KVA) | 100KW/125KVA | |
Max Output (KW/KVA) | 110KW/137.5KVA | |
Phase | 3 | |
Power Factor (cos Ø) | 0.8 | |
Rated Voltage (V) | 50HZ/1500RPM,400V | |
Rated Current (A) | 180A | |
Silent Genset Dimensions (MM)--N.W(KGS) | 3700*1400*1850--2950KGS | |
ENGINE | Model | CA6DF2-17D |
Type | In-line, six-cylinder, four-stroke | |
Aspiration | Turbocharged | |
Cooling mode | Water-cooling | |
12h Power (KW/KVA) | 125KW/156.25KVA | |
1hour Power (KW/KVA) | 138KW/172.5KVA | |
Bore×Stroke (MM×MM) | 110x125 | |
Displacement(L) | 7.13 | |
Compression Ratio | 17:1 | |
Fuel system | Mechanical | |
Lubricating oil capacity(with filter) (L) | 23 | |
Lubricating oil consumption(L/h) | 0.08 | |
Fuel Consumption(g/kw.h) | ≤202 | |
Air consumption (m3/min) | 9 | |
Permissible max. air intake resistance (kPa) | 6.3 | |
Amount of exhaust emission (m3/min) | 25 | |
Exhaust temperature after turbine (ºC) | 470 | |
Starting Type | Electric starting/12V | |
ALTERNATOR | Type | Copy Stamford-BS274D |
Rated Output (KW/KVA) | 100KW/125KVA | |
Max Output (KW/KVA) | 110KW/137.5KVA | |
Power Factor (cos Ø) | 0.8 | |
Excitation Mode | single-bearing with SAE ,Brushless synchronous ,Three harmonic exciting | |
AVR Model | SX460 | |
Insulation Class | H CLASS | |
IP Level (PROTECTION) | IP23 |
